Comprehensive Plug Cord Tester PM-PCT | Multi-Function High Voltage & Insulation Tester

USB Cable Tester USB Data Cable Tester | High-Speed 128/256 Point Testing with Hipot, Resistance & Insulation Check
Laser Diameter Controller Single Axis Laser Diameter Controller – Single Axis | Precision Measurement (0.1–30 mm)

The PM-PCT Plug Cord Tester is an advanced multi-function testing device for insulation, leakage current, and high voltage. Ideal for appliance cord quality assurance and electrical safety compliance.

Applications:

  • Power Cord Manufacturing & QA

  • Appliance Plug Safety Testing

  • Lab-based Electrical Compliance Testing

  • Wire & Cable Fault Detection

  • Electrical Safety Certification Preparation

Category:

Description

The Comprehensive Plug Cord Tester PM-PCT is a precision-engineered instrument designed for thorough testing of power cords and electrical plugs. Whether you’re manufacturing cords for household appliances or industrial-grade machinery, this tester ensures complete compliance with safety and insulation standards.

Operating at DC 500V insulation test voltage, Comprehensive Plug Cord Tester from Parovi Machines measures insulation impedance across selectable ranges (2 MΩ to 200 MΩ) and supports high-voltage (HV) testing up to AC 5kV, continuously adjustable for real-time flexibility. Its dual timer settings (0.1 ~ 99.9S) allow precise insulation and high voltage test durations.

With leakage current settings ranging from 0.5 to 10 mA, it identifies both internal and external faults effectively. This Comprehensive Plug Cord Tester also supports detection of wire induction degree ≥10 pF, ensuring the highest safety in plug and cord design validation.

Compact, efficient, and built to withstand rigorous industrial use, this Comprehensive Plug Cord Tester is a must-have in electrical labs, cord production units, and appliance QA testing lines.

Technical Parameters
MODEL PM-PCT
Insulation Test Voltage DC500V
Insulation impedance 2、7、20、50、100、200MΩ
Insulating time setting 0.1～99.9S
HV inside and outside AC 0~5KV Continuous adjustable
HV time setting 0.1～99.9S
Internal and external leakage current 0.5、1.0、2.0、3.0、5.0、10 mA
Wire induction degree ≥10 pF
Air Pressure ≤4Kgf/ C ㎡
Key Features & Benefits:

  • Dual Test Voltage Capabilities: DC 500V insulation and AC 0~5KV adjustable HV

  • Flexible Time Settings: Set insulation and HV tests from 0.1 to 99.9 seconds

  • Wide Leakage Current Range: 0.5 to 10 mA for detecting minor to major leakage

  • Multi-Point Impedance Options: Test across 2, 7, 20, 50, 100, and 200 MΩ

  • Wire Induction Detection: Ensures performance with ≥10 pF sensitivity

  • Optimized for Stability: Operates safely under ≤4 Kgf/cm² air pressure
