PRV-500 Vertical Back Twist Buncher with Take-Up | High-Speed Precision Bunching Machine

Double Twist Laying Machine For Lan Cable Double Twist Laying Machine for LAN Cable – Model PRV-DTL-800

High-performance vertical back twist buncher designed for fine conductor wires ranging from 0.32mm to 1.20mm. Achieve optimal pay-off speeds of up to 1000 RPM and take-up speeds up to 2000 RPM for efficient and precise bunching.

Applications:
Used in the production of communication cables, data cables, LAN cables, control cables, and other precision wire assemblies.



Category: Tags: , , , ,

Description

The PRV-500 Vertical Back Twist Buncher is a high-speed, precision-driven machine engineered for bunching fine conductor wires with exceptional consistency and speed. Ideal for copper or aluminum wire production lines, this machine features:

  • Its vertical structure ensures smooth wire feeding and consistent back twist control. The advanced control system enables minimal pitch variation, making it suitable for high-end cable manufacturing where uniformity and quality are critical.
  • Key Features:

    • Vertical back twist operation for high-twist quality

    • Supports fine wire diameters from 0.32mm to 1.20mm

    • Stable, vibration-free performance at high speeds

    • Maintenance-friendly design with long operational life

    • Compact footprint and user-friendly control interface

Technical Parameters
Machine Model PRV-500
Conductor Dia 0.32mm-1.20mm
Pay off Speed Max.1000 RPM
Take Up Speed Max2000RPM
Line Speed 300Mtrs./Min
Pitch Min.9.0 mm
