Power Cable Extruder Line – High Capacity Insulated Cable Production

Building Wire Jacketing Extrusion Lines Building Wire Jacketing Extrusion Line – High-Speed Precision Insulation
Teflon Extruder Line Teflon High Temperature Extruder Line – FEP / PFA / ETFE Wire Insulation Line

Heavy-duty Power Cable Extruder Line for insulated power cable production. Precision extrusion with high throughput, reliable controls, and large bobbin support.

APPLICATION:

Used in the production of:

  • Medium and high-voltage power cables

  • Industrial energy transmission cables

  • Insulated aluminum or copper cables

  • Underground and overhead power lines



LINE CONFIGURATION

The line is made up of gate type pay-off, caterpillar tractor, extrusion host, control panel, cooling trough, spark tester, pulling caterpillar, and take-up unit. Various accessories like printing machines, diameter controllers, PLCs, and touch screens can be added.

Category:

Description

Parovi Machines offers robust and high-output Power Cable Extruder Lines designed for the continuous extrusion of insulated electrical power cables. This Power Cable Extruder Line is built with dual-axis gate-type pay-off and take-up systems, this line delivers exceptional control, durability, and performance for heavy-duty cable production.

The Power Cable Extruder Line from Parovi Machines includes a high-capacity extrusion host, spark tester, cooling trough, caterpillar pulling units, and precision control panels. Supporting bobbins from PN630 to PN3150, Power Cable Extruder Line accommodates a wide range of wire sizes and insulation thicknesses. With scalable extrusion capacity up to 600 kg/hr, this Power Cable Extruder Line is ideal for large-diameter and high-voltage cable applications.

Optional upgrades such as diameter controllers, printers, PLCs, and touchscreen HMI can be integrated for smarter operation and automation. Designed for power cable manufacturers targeting superior insulation quality and consistent high-speed performance.

Technical Parameters

MODEL PRV-WE- 90 PRV-WE- 100 PRV-WE- 120 PRV-WE-150
Pay-Off Type Dual axis/gate type Dual axis/gate type Dual axis/gate type Dual axis/gate type
Pay-Off bobbin size (mm) PN630-800/1250 PN630-800/1250 PN1600-2000 PN2500-3150
Screw Diameter Ø 90 Ø 100 Ø 120 Ø 150
L/D ratio of Screw 25: 1 25 : 1 25: 1 25:1
Extrusion Capacity (kgs/hr) 280 350 400 600
Main Unit Power 50HP 70HP 100HP 150HP
Range of Wire Size Ø 3-25mm Ø 5-40mm Ø 50-80mm Ø 60-120mm
Cooling System Single Layer U Type Single Layer U Type Single Layer U Type Single Layer U Type
Capstan Power 7.5HP 10HP 15HP 20HP
Max Line Speed 200 200 150 100
Take-Up Type Dual axis/gate type Dual axis/gate type Dual axis/gate type Dual axis/gate type
