Vertical Super Fine Wire Drawing Machine – SMD100/24 High Precision
Super Fine Wire Drawing Machine
Achieve ultra-fine wire drawing with the Vertical Super Fine Wire Drawing Machine SMD100/24, featuring automatic tension control, dual inverter system, and 20–25% power savings.
Features
- Automatic tension control by DC or dual inverter.
- Zero slip pilot design, high productivity; good quality finished wire.
- Low power consumption, a reduction of 20-25% compared to the traditional type of machine.
- Description
Description
Vertical Super Fine Wire Drawing Machine – SMD100/24 | High-Precision, Energy-Efficient Solution
Engineered for exceptional performance, the SMD100/24 Vertical Super Fine Wire Drawing Machine is the perfect choice for producing ultra-fine wires. Equipped with an LCD computer interface and automatic digital tension control, it ensures precise, stable operations even at maximum speeds of 2000m/min. The zero-slip pilot design and energy-saving dual inverter control deliver outstanding productivity and a 20–25% reduction in power consumption compared to traditional machines.
Key Features:
-
Suitable for extremely fine wire diameters: 0.08mm to 0.20mm inlet, finished diameter down to 0.025mm.
-
Dual inverter system with LCD interface for easy control.
-
Ceramic coated capstans for enhanced durability.
-
Advanced flat belt drive for smooth, consistent wire drawing.
-
Automatic digital control of take-up for better wire quality.
-
High-speed production up to 2000 meters per minute.
-
Lightweight, efficient design reducing energy usage by up to 25%.
-
Compact footprint: 2.25 × 1.06 × 1.70 meters.
-
Magnetic brake system for added safety.
Technical Parameters
| Type | SMD100/24 |
|---|---|
| Control System | LCD computer interface |
| Power Control | Dual Inverter |
| Wire inlet dia | Ø0.08mm-Ø0.20mm |
| Wire finished dia | Ø0.025mm-Ø0.06mm |
| Maximum Wire Speed | 2000M/min |
| Max dies no | 24 |
| Transmission Type | Advanced flat belt drive |
| Mechanical Elongation | 8%+7% |
| Construction of the Machine Body Casting | Steel plated welded, vertical four shafts interface |
| Capstan | Ceramic coated |
| Capston dia (max) | Ø100mm |
| Fix Capston dia (max) | Ø100mm |
| Spool bobbin size | Ø190xØ157x198mm-Ø80 |
| Bobbin loading & unloading type | Single shaft cone |
| Max loading capacity | 12KG |
| Traversing unit | Flat Belt |
| Main Motor | 4kw |
| Spooler Motor | 1.5KW |
| Correction system | Automatic digital control of take-up |
| Tension control | Weight type tension pulley |
| Lubrication Type | Spray type |
| Lubrication type for bearing | Without oil |
| Power source | 415V/50Hz |
| Lubricant Capacity | 20L/min |
| Brake | Magnetic brake |
| Dimensions (lxwxh) | 2.25 x 1.06 x 1.70 M |
| Weight | 1500 kg |
Designed for manufacturers aiming to produce super-fine wires with the highest quality standards, the SMD100/24 promises unmatched efficiency, precision, and savings.
