Semi Automatic Folding and Binding Machine
Semi Automatic Folding and Binding Machine

Semi Automatic Folding and Binding Machine

Automatic Folding and Round Type Binding Machine Automatic Folding and Round Type Binding Machine
Low Noise Crimping Presses Machine Low Noise Crimping Presses Machine

Model no.

PRV-WP-9030/ 9040

Application

Semi-Automatic Folding & Binding Machine

Features

The machine is capable of processing AC Power Cords, DC Power Cords, Audio Video Cords, HDMI Cords, and USB Cords to fold and bind Tie wire to further use it to put into packaging box or bag.
The operator has to use the pedal to fold the wire first on the rotary table mechanism and then put it into the second mechanism to Tie it up. The number of rotations of the turn table is fed into the digital operating system depending on the length of each cord.

Category:

Description

Technical Parameters

MODEL PRV-WP-9030 PRV-WP-9040
Bunch Length 80 ~ 140 mm 110 ~ 190 mm
Diameter of Bunch 10 ~ 30 mm 20 ~ 45 mm
Binding Speed 1 Pc. / Sec. 1 Pc. / Sec.
Folding Pitch 50 ~ 200 mm 50 ~ 200 mm
Folding Speed 1 ~ 10 Sec. Adjustable 1 ~ 10 Sec. Adjustable
Power Supply 220 V AC 50 Hz. Single Phase 220 V AC 50 Hz. Single Phase
Size 700 x 550 x 400 mm 700 x 550 x 400 mm
Weight 45 Kg 45 Kg
